Mini210S (1G Flash) + 7"LCD resistive LCD (S70) + Standard Accessories

  • Dimension: 110 x 110 mm     
    CPU: 1GHz Samsung S5PV210 with PowerVR SGX540 graphics engine
    RAM: 512 MB, 32 bit Bus
    Flash: up to 2GB NAND Flash
    EEPROM: 256 Byte (I2C)
    Ext. Memory: microSD-Card socket
    Serial Ports: 1x DB9 connector (RS232), total: 4x serial port connectors
    USB: 1x USB-A Host 2.0, 1x miniUSB Slave/OTG 2.0
    Audio Output: 3.5 mm stereo jack, connector for a speaker (Class D Amp)
    Audio Input: Condenser microphone
    Ethernet: RJ-45 10/100M (DM9000)
    RTC: Real Time Clock with battery
    Beeper: PWM buzzer
    Camera: 2x 20 pin (2.0 mm) Camera interface
    Monitor: miniHDMI
    LCD Interface: 24 pin (2.0 mm) MIPI and 41 pin connector for FriendlyARM Displays
    User Inputs: 4x push buttons and 1x A/D pot
    User Outputs: 4x LEDs
    Expansion: 40 pin GPIO, 20 pin SDIO (SD, SPI, I2C), 20 pin Buttons/Keypad (2.0 mm)
    Debug: 10 pin JTAG (2.0 mm)
    Power: regulated 5V (DC-Plug)
    OS Support:Windows CE 6 Linux Android
  • TEKLİF AL

Mini6410 (1G Flash) + 7"LCD + Standard Accessories

  • Dimension: 110 x 110 mm     
    CPU: 533MHz Samsung S3C6410A ARM1176JZF-S with VFP-Unit and Jazelle (max freq. 667 MHz)
    RAM: 256 MB, 32 bit Bus
    Flash: up to 1GB NAND Flash
    EEPROM: 256 Byte (I2C)
    Ext. Memory: SD-Card socket
    Serial Ports: 1x DB9 connector (RS232), total: 4x serial port connectors
    IR: Infrared Receiver
    USB: 1x USB-A Host 1.1, 1x miniUSB Slave/OTG 2.0
    Audio Output: 3.5 mm stereo jack
    Audio Input: Condenser microphone
    Ethernet: RJ-45 10/100M (DM9000)
    RTC: Real Time Clock with battery
    Beeper: PWM buzzer
    Camera: 20 pin (2.0 mm) Camera interface
    TV Output: AV Out
    LCD Interface: 40 pin (2.0 mm) and 41 pin connector for FriendlyARM Displays and VGA Board
    User Inputs: 8x push buttons and 1x A/D pot
    User Outputs: 4x LEDs
    Expansion: 40 pin System Bus, 30 pin GPIO, 20 pin SDIO (SD, SPI, I2C), 10 pin Buttons (2.0 mm)
    Debug: 10 pin JTAG (2.0 mm)
    Power: regulated 5V
    OS Support:Windows CE 6 Linux, Ubuntu, Android
  • TEKLİF AL

Mini2440 (256M Flash) + 7"LCD + Standard Accessories

  • Dimension: 100 x 100 mm
    CPU: 400MHz Samsung S3C2440 ARM926T (max freq. 533 MHz)
    RAM: 64 MB, 32 bit Bus
    Flash: up to 1GB NAND Flash
    EEPROM: 256 Byte (I2C)
    Ext. Memory: SD-Card socket
    Serial Ports: 1x DB9 connector (RS232), total: 3x serial port connectors
    USB: 1x USB-A Host 1.1, 1x USB-B Device 1.1
    Audio Output: 3.5 mm stereo jack
    Audio Input: Connector + Condenser microphone
    Ethernet: RJ-45 10/100M (DM9000)
    RTC: Real Time Clock with battery (CR1220)
    Beeper: PWM buzzer
    Camera: 20 pin (2.0 mm) Camera interface
    LCD Interface: 41 pin connector for FriendlyARM Displays and VGA Board
    User Inputs: 6x push buttons and 1x A/D pot
    User Outputs: 4x LEDs
    Expansion: 40 pin System Bus, 34 pin GPIO, 10 pin Buttons (2.0 mm)
    Debug: 10 pin JTAG (2.0 mm)
    Power:regulated 5V (DC-Plug: 1.35mm inner x 3.5mm outer diameter)
    Power Consumption:Mini2440: 0.3 A, Mini2440 + 3.5" LCD: 0.6 A, Mini2440 + 7" LCD: 1 A OS Support
    OS Support:Windows CE 5 and 6 Linux
